Approximate Closing Flows Vapor SCFH Propane 100 (psig) Inlet 48600 scfh
Approximate Closing Flows Vapor SCFH Propane 25 (psig) Inlet 28590 scfh
Inlet Connection (in.) 2" F. NPT
Outlet Connection (in.) 2" F. NPT
Approximate Closing Flows Liquid Gpm Propane 170 GPM
Brand RegO
Connection Type F. NPT x F. NPT
D Effective Length Approx 4 9/16”
E Threaded End To Port -
Materials 1519C2 |Body, Brass |Valve Poppet w/Stem, Brass |Spring, Stainless Steel |Guide, Brass 1519C4 |Body, Brass |Valve Disc, Cadmium Plated Steel |Stem, Stainless Steel |Spring, Stainless Steel |Guide, Ductile Iron
Typical Installation Pipeline
Wrench Hex Flats 3”
